英特尔凌动C3000处理器(Denverton-NS)
2个DDR4 ECC 2133MHz内存，最大32GB
板载8个RJ45 GbE接口，最多16个RJ45/SFP GbE接口
CASwell网卡模块最多支持1个PCIe Gen3 x 2
可选QAT功能
可选eMMC
平台
处理器
1 x Intel Atom C Processor (Denverton-NS)
系统内存
2 x DDR4 ECC 2133MHz UDIMMs (Up to 32GB)
网络接口
8 x RJ45 GbE Port(s) on board Up to 16 x Ethernet Port(s) with maximum 16GbE bandwidth
Bypass
2 segment(s) on board
扩充
Up to 1 PCIe Gen3 x 2 for CASwell NIC Module
储存装置
1 x 3.5’’ or 2 x 2.5” SATA HDDs 1 x CF Socket
电源供应
100W Single PSU
尺寸 (宽x深x高)
438mm x 300mm x 44mm (17.52" x 12" x 1.76")
I/O
管理接口
1 x RJ45 System Console Port 1 x Micro USB Console Port
USB接口
2 x USB 3.0 Port(s)
Display接口
1 x VGA Port (Optional from Convert Board for NIP)
LCD面板
128 x 32/64 Graphic, 2 x 16 Characters
LED
Power / HDD / Ethernet / Bypass
操作环境 & 认证
操作环境
Temperature: 0 - 40°C (32 - 104°F) Humidity: 20 - 90% RH
储存环境
Temperature: -10 - 70°C (14 - 158°F) Humidity: 5 - 95% RH
认证
CE / FCC
操作系统支持
Linux
